Menyoroti
double-sided FPC circuit membrane
,flexible printing membrane switch
,printed FPC circuit switch
-
Model TIDAK.HC-FPC-002
-
Modus KombinasiPelat Fleksibel Perekat
-
Perekat KonduktifPasta Perak Konduktif
-
Tahan ApiHB
-
Teknologi Pengolahanfoil elektrolitik
-
Bahan DasarAluminium
-
Bahan isolasiresin organik
-
Ketebalan Rata-rata1.1-0. Pagi
-
Jenis Foil TembagaElektrolit dan Digulung
-
Ketebalan Foil Tembaga1 ons, 1/2 ons, 1/3 ons
-
Ketebalan Film Substrat1 juta, 1/2 juta
-
Ketebalan Film Sampul1 juta, 1/2 juta
-
Ketebalan Pengaku3mil hingga 9mil
-
Kapasitas Produksi100.000 pcs/bulan
-
Kode Hs8536500000
-
Kuantitas min Order100
Double-Sided Flexible Printing Membrane Printed FPC Circuit
Double-Sided Flexible Printing Membrane Printed FPC Circuit
Double-sided flexible printed circuit (FPC) boards offer exceptional flexibility and reliability for advanced electronic applications requiring compact, lightweight solutions.
Key Features and Benefits
- Exceptional Flexibility: Can be bent, folded, and deformed freely with small coil radius and movement along X, Y, Z axes
- Space-Saving Design: Light and thin construction (average thickness 1.1-0.1mm) maximizes use of narrow instrument spaces
- Lightweight Construction: Optimized for current load rather than mechanical strength, resulting in minimal weight
- Superior Sealing Capability: Designed for low-tensile seal performance in adverse environments
- Stable Signal Transmission: Freely designed wiring patterns and conductor distances ensure steady RLC parameters
- Easy Assembly: Excellent terminal properties for soldering, inserting, riveting, and gluing applications
- Enhanced Insulation: Materials like polyimide and polyester provide superior insulation properties
Material Composition
Copper Foil Substrate:
- Copper Foil: Electrolytic copper and rolled copper (common thickness: 1oz, 1/2oz, 1/3oz)
- Substrate Film: Common thickness of 1mil and 1/2mil
- Adhesive: Thickness customized to customer requirements
Cover Film Protection:
- Cover Film: Surface insulation (common thickness: 1mil and 1/2mil)
- Adhesive: Thickness customized to customer requirements
- Prevents adhesive buildup and foreign matter before pressing
Stiffener (PI Stiffener Film):
- Reinforces mechanical strength for surface mounting
- Common thickness: 3mil to 9mil
- Adhesive: Thickness customized to customer requirements
EMI Shielding: Electromagnetic shielding film protects circuit board lines from external interference in high electromagnetic environments.
Competitive Advantages
- Shorter Assembly Time: Complete line configuration eliminates extra PCB wiring connection work
- Compact Size: Small volume PCB effectively reduces product dimensions
- Lightweight: Significantly lighter than traditional rigid PCBs
- Thin Profile: Thinner than hard PCB boards, improving flexibility and 3D assembly capabilities
- Quick Delivery
- Premium Services
- OEM/ODM Customization Available
